Aqualifter – pool lift that can also be used for salt water
The Aqualifter is a fully automated lift for people with disabilities that enables safe, easy and independent entry into and exit from water. It is made of stainless steel inox 316, which is resistant to the conditions found along the sea coast.
Additional description
The Aqualifter is an automated aid for people with disabilities that safely enables independent entry into and exit from water, without the help of other people.
Using the Aqualifter is easy with a radio remote control. The seat automatically lifts and turns with the help of an electric motor, allowing the user to enter water with minimal effort and maximum safety.
The Aqualifter is designed according to the configuration of the terrain on which it is installed and according to the specific requirements of the user or investor. The robust construction is adapted for use in public areas. The lift is made of stainless steel inox 316, which is resistant to atmospheric conditions present along the sea coast.
After the season, there is the possibility of additional customisation of the Aqualifter according to the user's wishes. With its simple design, choice of colours, and customisable appearance, the Aqualifter blends beautifully into its surroundings.
Technical specifications
| Property | Data |
|---|---|
| Name | Aqualifter |
| Capacity | 120 kg |
| Seat lifting and turning | Automated seat lifting and turning by 90° |
| Control | Wireless radio remote control |
| Supply voltage | 230 V, 50 Hz |
| Installed power | 2.3 kW |
| Control voltage | 24 V DC |
| Lifting height | 0.2–2.5 m, depending on the investor’s requirements |
| Minimum water depth | 1 m |
| Seat adjustment | Possibility of dismantling and adjusting the seat angle for lowering into the sea |
| Material | Stainless steel inox 316 |
| Mass | Approximately 200 kg |
| Lift anchor | Base plate for base fixing + anchor bolts M16 × 500 mm |
| Protection | Protection in accordance with regulations on the protection of assets for public use |
| Documentation | Product declaration of conformity, CE certificate and instructions for use |
| Service | Guaranteed elevator servicing and maintenance |
| Warranty | Standard 12 month warranty |
Additional options:
– control from the seat or housing,
– additional remote control,
– seat at an angle of 45° or 90°,
– solar power,
– protective fence,
– choice of colours: coat, seat, arm.
